Technical Specifications | T5 | T8 |
Article Number | 10-03105-010 | 10-03108-010 |
Max.Gate Weight | 500kg | 800kg |
Max. Gate Width | 6m | 6m |
Max. Pulling Force (When Started) | 25kgf | 25kgf |
Max. Pulling Force (When Running) | 15kgf | 15kgf |
Max. Speed | 200mm/s | 150mm/s |
Duty Cycle | 0.4 | 0.4 |
Rated Current/ Max. Current | 3A/10A | 3A/10A |
Nominal Input Voltage | 220V AC± 10%,50/60Hz | 220V AC± 10%,50/60Hz |
Motor | 24V DC | 24V DC |
Transformer | 100W | 200W |
Degree of Protection | IP54 | IP54 |
Slow Start / Slow Stop Function | Yes | Yes |
Safety Obstruction Sensing | Yes | Yes |
Connect to APPLink Smartphone Controller | Available | Available |
Operating Temperature | -20℃ to +50℃ | -20°℃ to +50℃ |
Radio | KEELOQ Hopping Code, 433 MHz | KEELOQ Hopping Code, 433 MHz |
TX Capacity | Standard 2,Max. 27 Transmitter | Standard 2,Max.27 Transmitter |
Max. Distance | 80m | 80m |
Weight | 9.5kg | 12kg |
